Products Center

Location：Home > Products > Single And Twin Screw Plastic Extruder >

Product Details
  • Single screw extruder

Single screw extruder

  • Update：2019-10-14 17:13:51
  • Category：
  • Model：
  • Price：
  • TAG：

INSTRUCTIONS

Single screw extruder use:
The single-screw extruder is mainly used for extruding soft and hard polyvinyl chloride, polyethylene and other thermoplastic plastics. It can process a variety of plastic products, such as films, tubes, etc., in conjunction with corresponding auxiliary machines (including molding heads). Rods, plates, wires, cable insulation and hollow products can also be used for granulation.
The single-screw extruder has advanced design, high fan output, good plasticization and low energy consumption. It adopts involute gear transmission and has the characteristics of low noise, stable operation, large bearing capacity and long life.

PARAMETER

Main technical parameters of single screw extruder:

 Product Name  Screw diameter
(mm)		  L/D  Motor power
kW		  output
Torque(N.M)		  Screw speed
(r/min)		  Max output
(kg/h)
SJ25/25 25 25:1 1.5 175 100 3.4
SJ30/25 30 25:1 5.5 410 125 12.5
SJ45/25 45 25:1 7.5 580 100 20
SJ45/30A 45 30:1 15 1000 145 40
SJ45/30C 45 30:1 30 1600 185 120
SJ65/25 65 25:1 22 1500 100 60
SJ65/30 65 30:1 30 3600 105 80
SJ65/30 65 30:1 45 4800 120 120
SJ75/32 75 32:1 90 7200 120 350
SJ90/25 90 25:1 55 4400 120 150
SJ90/30 90 30:1 90 9200 94 250
SJ90/32 90 32:1 160 13000 120 500
SJ120/25 120 25:1 90 9200 94 350
SJ120/30 120 30:1 110 16000 94 350
SJ120/33 120 33:1 250 25000 94 800
SJ150/25 150 25:1 110 35000 40 320
SJ150/30 150 30:1 132 36000 50 350
SJ150/34 150 34:1 315 32000 75 1100
SJ200/25 200 25:1 160 50000 30 500
SJ200/30 200 30:1 200 60000 40 550
SJ200/34 200 34:1 400 55000 75 1500
